What is Type 2 insulation

TYPE II · 20 PSI. Page 1. Description. InsulFoam II Below Grade is an engineered insulation consisting of a superior closed-cell, lightweight and resilient expanded polystyrene (EPS).

What is the difference between Type 1 and Type 2 insulation?

Type 1 polystyrene insulation has a typical thermal resistance value or R3. 7/in., while Type 2 polystyrene insulation has a minimum thermal resistance value of R4. 0/in. Type 1 is moulded bead polystyrene.

What is R-value of 2 rigid insulation?

With an R-value of 13.1 for a 2″ thick sheet only two 2″ sheets are required to achieve R-25. 2. Extruded polystyrene or XPS (foam is usually pink or blue) XPS has an R-value of 5 per inch of thickness requiring 5″ of insulation to achieve R-25.

What is Type 2 foam insulation?

PlastiSpan HD Insulation is a Type 2, moulded expanded polystyrene (EPS) insulation with an R-value of 4.04 per inch and compressive resistance of 16 psi. … PlastiSpan HD EPS is a closed cell, rigid foam plastic insulation that maintains its R-value for the life of the product.

What is Type 4 insulation?

Type 4 XPS Insulation Board. Page 2. Description. Kingspan GreenGuard™ Type 4 XPS Insulation Board comprises closed–cell extruded polystyrene (XPS) with a minimum compressive strength of 60 psi. It has high water resistance and R–value of 5.0 per inch of thickness.

What is the R value of 2 inch foam board?

A wall utilizing STYROFOAM T-MASS Technology with a 2-inch exterior layer and a 4-inch interior layer of concrete along with a 2-inch layer of STYROFOAM extruded polystyrene insulation would result in a material R-value of approximately 11.33.

Which is better XPS or EPS?

XPS, at about R-5 per 25 mm, has only a slightly better thermal performance than EPS. The thermal insulation performance of EPS and XPS in identical densities is quite close. However, EPS with the same level of density is less expensive.

Can you put fiberglass insulation over foam board?

insert foam board between the studs to seal everything up tight, and then install fiberglass batts over the foam board. Finish with plastic stapled to the studs, then drywall.

What is the difference between EPS and styrofoam?

As we said, Styrofoam™ is a Dow trade, blue in color, and is an extruded polystyrene (XPS) foam made for thermal insulation, construction and craft applications. EPS is an expanded polystyrene available in various densities for insulation, construction and craft applications and so much more.

What is a good R-value?

Typical recommendations for exterior walls are R-13 to R-23, while R-30, R-38 and R-49 are common for ceilings and attic spaces. See the Department of Energy’s (DOE) ranges for recommended levels of insulation below.

Article first time published on

What is the difference between pink and blue foam board?

Main Difference Between Pink And Blue Foam Boards Both are manufactured using the same process and contain similar chemical components. … However, blue foam boards are manufactured by Dow Chemical Co. whereas the pink foam boards are manufactured by Owens Corning company.

Can you use Styrofoam as insulation?

Styrofoam is also a material that has great insulating properties. … I could make a wooden form, then create blocks of insulation that would fit between the 2 x 4 stud walls.

What is the R-value of 2 inch Blueboard insulation?

DOW BLUE BOARD 2″ 2’X8′ 250 PSI R-VALUE=10.8.

What is the R-value of 3.5 batt insulation?

R-value of Materials and DepthsMaterialR-value/in5 1/4″Fiberglass (batt)3.1 – 3.416.3 – 17.8Fiberglass blown (attic)2.2 – 4.311.5 – 22.6Fiberglass blown (wall)3.7 – 4.319.4 – 22.6

What is the R-value of 4 inch fiberglass insulation?

Blown-in fiberglass has an R-value of 2.2 to 2.7 per inch. Batts. Fiberglass batts and rolls are ideal for placement between framing during construction in floors, walls, attics, and ceilings. They’re denser than blown-in insulation, offering an R-value of up to 4.3 per inch.

What is the R-value of 6 inch Styrofoam?

Extruded Polystyrene Foam XPS has an R value of 4.5 to 5.0 per inch of thickness.

Is EPS foam closed cell?

Expanded Polystyrene Insulation, more commonly referred to as EPS, is a closed cell insulation that has been around since the 1950’s. EPS is made of 98% trapped air and only 2% plastic, making it an efficient insulator with a small amount of raw material.

What kind of foam goes under slab?

Rigid foam insulations, such as expanded polystyrene (EPS), have been used successfully under concrete slabs for more than 40 years. Such insulation helps reduce heat loss to the ground in residences, cold storage units, warehouses and other commercial, institutional and industrial structures.

Which side of Styrofoam insulation faces out?

If you’re wondering whether to put the foil side of foam insulation board shiny side in or out, consider whether you want to make the space inside warmer or cooler. If you want to make the space warmer, the foil should face inside so it can reflect radiant heat back into the room.

Does drywall have an R-value?

Drywall, for instance, has an R-value of about R-0.5 for its half-inch of thickness. This is quite minimal when you consider that filling a four-inch-thick wall cavity with insulation increases the R-value to about R-15.

How thick should foam board insulation be?

It comes in standard-size 4×8 sheets, and smaller sizes, in many different thicknesses from 1/4 inch to 2 inches. Some types of thicker foam board insulation are available, but they may need to be special ordered. Foam board insulation is easy to use and is a great DIY way to add some insulation.

Why is Styrofoam bad?

Polystyrene is slow to degrade, and if disposed of improperly, the foam can leach chemicals into the environment harming water sources. Polystyrene manufacturing is an enormous creator of hazardous waste. Furthermore, polystyrene manufacturing greatly contributes to global warming.

Does breaking Styrofoam release toxins?

Styrofoam will break down into microscopic styrenes and other harmful chemicals, and they will linger in the soil and water for centuries to come. It’s an especially serious problem in our world’s oceans.

Is EPS foam waterproof?

While polyiso, XPS and EPS have some of the strongest waterproofing properties of all insulations, EPS is the weakest of the three and absorbs more water. EPS is also susceptible to crumbling on the edges.

Does foam board insulation need an air gap?

If you plan to fill the stud bays with airpermeable insulation (fiberglass batts, blown-in fiberglass, mineral wool, or cellulose), the material you use to create the air gap needs also to be an air barrier. The most common choice is rigid foam. … The idea is to create an air gap between the siding and the rigid foam.

Does stacking insulation increase R-value?

DIY Frequently Asked Questions / Can I stack insulation to get a higher R-value? Yes. For example, two R-19 batts can be stacked on each other to create R-38 insulation. You also can add loose-fill insulation on top of a bottom layer of batts.

Can you put rigid foam insulation between studs?

Even with its flaws—namely, its inability to perfectly mold to the bays between the studs—rigid foam insulation will be a better bet than no insulation. Using low-expanding spray foam sealant to seal those gaps further increases rigid foam’s insulating properties between studs.

What is r14 insulation used for?

Description. Specifically engineered to use in exterior walls, cathedral ceilings, attics, basement walls, exposed floors, and heated crawl spaces. Easily cut, non-combustible, excellent sound absorbency. Does not rot or sustain vermin, does not promote growth of fungi or mildew.

Which insulation is best for attic?

Many people consider fiberglass batt to be the best attic insulation. It consists of plastic reinforced by small glass fibers. The batt version comes in blanket form — i.e., small, pre-cut sections that you can lay down wherever you need to.

What is a good r2 value?

In other fields, the standards for a good R-Squared reading can be much higher, such as 0.9 or above. In finance, an R-Squared above 0.7 would generally be seen as showing a high level of correlation, whereas a measure below 0.4 would show a low correlation.

What kind of foam is Pink Panther?

Pink Panther Insulation Foam. This Insulation Is Moisture Resistant XPS Insulation Foam Board.
