What size water lines are in RV

In RVs, manufacturers typically use translucent non-colored PEX for all plumbing runs. Further, two sizes are used, 3/8-inch and ½-inch. These are the standard size because the outside diameter of the tubing is about 1/8-inch greater than the called-for size. Also, PEX is inexpensive.

What kind of water lines are in a RV?

RV Plastic Water Lines Modern RVs use PEX pipe or PEX tubing. It is cheaper and easier to install than metal tubing. PEX tubing comes in all colors, but red tubes are normally used for hot water, and blue ones for cold water. Manufacturers, looking to cut costs, usually use a white tube for both hot and cold water.

Can you use PEX in RV?

Pex tubing is lightweight, but durable to withstand the pressurized water coming into the RV unit. If you have an older RV with the old water line system, you can easily replace the water lines using Pex tubing.

What size should my water lines be?

In most cases, the main pipeline from the street to your home is either 3/4 or 1 inch in diameter, supply branches use 3/4-inch-diameter pipe, and pipes for individual components are 1/2 inch. Remember that water pressure decreases by a half-pound per square inch for every foot pipes extend above your water supply.

What are the red and blue lines under my RV?

They are the “low point” drains. Blue is the cold and red is the hot side. For those that winterize their RV they are used to drain all the water from the fresh water system. If you take the caps off, or open the valve, then open all the faucets and such inside and out, gravity will drain all the water.

What is PEX water line?

PEX, short for cross-linked polyethylene, is a flexible plastic used for plumbing. The tubing has become quite popular over the years, replacing traditional copper and galvanized steel water supply lines.

What size is a RV toilet supply line?

Almost every common RV toilet uses a 1/2″ FPT or MPT fitting at the water entry (generally MPT). If you are using 1/2″ PEX and the associated Shark Bite fittings, then they have one that terminates with a 1/2″ MPT thread.

How many fixtures can 3/4 water line supply?

On an 3/4″ supply line you can have two fixtures working together continuously but if, the supply is from Over Head Tank with 20 ‘ head than 3 at a time. So a 3/4″ line is sufficient for a toilet. You should go in for 1″ water line in case you have bath tub too to fill.

How do I calculate water pipe size?

1 inch= 25.4mm, 1 ft. = 304.8mm, 1 gallon/m=3.785L/m. Water velocity should not be greater than 2.438m/s at valve seat to prevent noise and erosion. So, Pipe area should be at least equal to water flow rate divided by eight.

Does increasing pipe size increase water pressure?

Increasing pipe size doesn’t increase the pressure of standing (still) water; but, it has the effect of reducing resistance (pressure drop) in flowing water. When flow is in a narrow pipe, there is some pressure drop along the pipe. If a larger diameter pipe is used, the pressure drop per foot of pipe is less.

Article first time published on

What size is the PEX pipe in an RV?

In RVs, manufacturers typically use translucent non-colored PEX for all plumbing runs. Further, two sizes are used, 3/8-inch and ½-inch. These are the standard size because the outside diameter of the tubing is about 1/8-inch greater than the called-for size. Also, PEX is inexpensive.

What size PEX do RVs use?

Most common size is 1/2”.

What is an RV low point drain?

The low point drain drains the water system. Meaning its the lowest point in the water system.

What size are RV faucet lines?

Most RVs use 1/2” female connections for water supply lines. I purchased two lead-free 1/2” to 3/8” compression adapters.

What size is RV sewer pipe?

The size of a camper sewer line is 3 inches in diameter. The rigid pipe used for the camper sewer outlet is 3 inches, as is the diameter of sewer hoses that connect to the RV’s waste outlet pipe.

Where are Dometic toilets made?

Dometic toilets are built to last with a highly durable plastic and china material. Dometic is located within the United States, so you know you get a good quality product when you buy a new Dometic RV toilet.

Why is PEX plumbing bad?

Potential chemical leaching is another downside of PEX piping. Due to its chemical composition, the PEX pipe material may leach toxic chemicals including bisphenol (BPA), MTBE, tertiary butyl alcohol (TBA), and others.

Is PEX safe for drinking water 2020?

The inner pipe for drinking water is made of a plastic called cross-linked polyethylene (PEX). … There are no health risks associated with drinking water from PEX pipes. A few types of PEX-pipe may cause prolonged undesirable taste and odour if the water remains in pipes over time.

What is better PEX A or PEX B?

PEX A vs PEX B: Burst Pressure Bottom line, PEX A is more resistant to burst pressure than PEX B. PEX A’s expansive material can handle up to 500 PSI, which makes it reliable in extremely cold temperatures. Since PEX B is a more rigid material, it will not hold up as well in similar situations.

How do I choose a pipe size?

The equation for pipe diameter is the square root of 4 times the flow rate divided by pi times velocity. For example, given a flow rate of 1,000 inches per second and a velocity of 40 cubic inches per second, the diameter would be the square root of 1000 times 4 divided by 3.14 times 40 or 5.64 inches.

What are standard pipe sizes?

NPSOutside Diameter (in)Weight (lb/ft)1/40.540″0.42 lb/ft3/80.675″0.57 lb/ft1/20.840″0.85 lb/ft3/41.050″1.13 lb/ft

What is the flow rate of a 1-inch pipe?

Assume Average Pressure (20-100PSI). About 12 f/s flow velocity1/2″0.5 – 0.6″143/4″0.75 – 0.85″231″1 – 1.03″371-1/4″1.25 – 1.36″62

What is the standard size water supply line?

The main pipes, which come off the main water supply, typically measure 3/4 inches in diameter. The branch lines, which feed individual fixtures, typically measure 1/2 inch in diameter.

Can I use 3/4 PEX for a main water line?

PEX tubes range in diameter from 3/8-inch to 1-inch for residential applications. For adequate water flow, it’s a good idea to install 1/2-inch or 3/4-inch PEX for your main lines. The standard when replacing old water supply lines with PEX is to use the same size.

How do you size a water line?

1. Add up the total number of water supply fixture units (wsfu) required in the facility.
2. Estimate demand using the table from the IPC that correlates wsfu to expected demand.
3. Size the pipe using demand vs. friction loss curves found in the IPC charts.

What happens when you increase pipe size?

A larger pipe, and lower velocity, has less pressure loss. The fittings in a larger pipe also have less pressure loss. So, all things considered, if you want to lose less pressure through a series of pipes and fittings, you increase the size.

How high does a water tank need to be for good pressure?

Your well tank’s pressure should be set at 2 psi below the pressure switch’s cut-on point. This differs depending on your tank’s pressure settings. Most well tanks come set at 30/50. The cut-on pressure for the well pump is 30 psi, so the pressure of the tank should have a pressure of 28 psi.

What are the red and blue hoses under my camper?

The Red and Blue are your low point drains. If they’re the typical arrangement, when the “T” or ( “L” handle) is at right angles to the standing part of the fitting when the valve is closed. You will also find another hose sticking down, probably white or grey, that is your fresh water tank drain.

Why is my camper leaking water underneath?

The most common places for water to enter the RV are punctures in the roof, siding that is coming loose, or a weak seam that needs reinforcing. If you’ve had some recent damage to the RV, driving under low-hanging branches, or impact from a collision, it may be obvious to you where the hole is.

When were polybutylene pipes used?

Polybutylene (PB) was a plastic manufactured between 1978 and mid-1995 for use as piping in home plumbing systems. It was inexpensive and offered plenty of advantages over other materials, such as flexibility, ease of installation, resistance to freezing.

Can I use PEX fittings on polybutylene pipe?

PB has the same outside diameter as PEX of the same nominal size, but outside diameters differ slightly between the tubing types. This means that you should not use PEX fittings on polybutylene, but that you can use PEX crimping rings and PEX crimping tools on barbed PB connections.
